867052-1的详细信息
| Manufacturer： | TE Connectivity |
|---|---|
| Product Category： | Headers & Wire Housings |
| RoHS： | No |
| Brand： | TE Connectivity / AMP |
| Product Type： | Contacts |
| Pitch： | - |
| Number of Positions： | - |
| Number of Rows： | - |
| Contact Plating： | Tin |
| Housing Material： | - |
| Termination Style： | Crimp |
| Mounting Style： | - |
| Mounting Angle： | - |
| Contact Material： | Phosphor Bronze |
| Current Rating： | 3 A |
| Latching Type： | - |
| Mating Post Length： | - |
| Operating Temperature Range： | - 65 C to + 105 C |
| Packaging： | Reel |
| Row Spacing： | - |
| Factory Pack Quantity： | 7000 |
| Termination Post Length： | - |
| Voltage Rating： | 250 VAC |
| Wire Gauge： | 20 |
867052-1相关文档
- Product Specification: Connector, Locking Clip, .025 Inch Square, Tin
- Instruction Sheet (U.S.): AMPMODU Locking Clip Contacts and Housings for 0.64mm Square Posts
- 3D Model: Customer View Model
- Qualification Test Report: Connector, Locking Clip, .025 Inch Square, Tin
- Customer Drawing: CONTACT ASS'Y, LOCKING CLIP. FOR .025 SQUARE POST.
- Application Specification: Locking Clip 0.64-mm (.025-in.) Square Contacts and Housings
