ATmega128-16AU的详细信息
| Manufacturer： | Atmel |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | Atmel |
| Core： | AVR |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 16 MHz |
| Program Memory Size： | 128 kB |
| Data RAM Size： | 4 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 4.5 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | TQFP-64 |
| Mounting Style： | SMD/SMT |
| Data RAM Type： | SRAM |
| Data ROM Size： | 4 kB |
| Data ROM Type： | EEPROM |
| Interface Type： | 2-Wire, JTAG, SPI, USART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 53 |
| Number of Timers： | 4 |
| Processor Series： | megaAVR |
| Program Memory Type： | Flash |
| Series： | ATMEGA 128 |
| Factory Pack Quantity： | 90 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 4.5 V |
| Tradename： | ATMEGA |
