SBC807-16LT3G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | Transistors Bipolar - BJT |
| RoHS： | Yes |
| Configuration： | Single |
| Transistor Polarity： | PNP |
| Collector- Base Voltage VCBO： | 50 V |
| Collector- Emitter Voltage VCEO Max： | 45 V |
| Emitter- Base Voltage VEBO： | 5 V |
| Maximum DC Collector Current： | 0.5 A |
| Gain Bandwidth Product fT： | 100 MHz |
| Maximum Operating Temperature： | + 150 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23 |
| Brand： | ON Semiconductor |
| DC Collector/Base Gain hfe Min： | 100 at 100 mA at 1 V, 40 at 500 mA at 1 V |
| DC Current Gain hFE Max： | 100 at 100 mA at 1 V |
| Maximum Power Dissipation： | 300 mW |
| Minimum Operating Temperature： | - 55 C |
| Packaging： | Reel |
| Series： | BC807-16L |
| Factory Pack Quantity： | 10000 |
SBC807-16LT3G相关文档
- PCN: ON Semiconductor - PCN 6-2-10
- PCN: On Semiconductor - PCN 5-21-10
- Simulation Model: BC807-16LT1G LIB Model
- Simulation Model: BC807-16LT1G SP2 Model
- Package Drawing: SOT-23 (TO-236) 3 LEAD
- Simulation Model: BC807-16LT1G SP3 Model
- Simulation Model: BC807-16LT1G SIN Model
