BUK9529-100B,127的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 100 V |
| Vgs - Gate-Source Breakdown Voltage： | 15 V |
| Id - Continuous Drain Current： | 46 A |
| Rds On - Drain-Source Resistance： | 27 mOhms |
| Configuration： | Single |
| Maximum Operating Temperature： | + 175 C |
| Pd - Power Dissipation： | 157 W |
| Mounting Style： | Through Hole |
| Package / Case： | TO-220-3 |
| Packaging： | Tube |
| Channel Mode： | Enhancement |
| Fall Time： | 46 ns |
| Minimum Operating Temperature： | - 55 C |
| Rise Time： | 86 ns |
| Factory Pack Quantity： | 50 |
| Typical Turn-Off Delay Time： | 96 ns |
| Part # Aliases： | BUK9529-100B |
BUK9529-100B,127相关文档
- Brochure: Power MOSFETs for Automotive Applications; Performance, Quality, Reliability (v.1.0)
- Application note: Understanding Power MOSFET Datasheet Parameters (v.1.0)
- Selection guide: NXP's Power MOSFET Selection Guide 2012; Smaller, faster, cooler (v.2.1)
- PCN: Standardisation of Bill of Material for SOT78/SOT226 Automotive
