VQB100R-T110-S24的详细信息
| Datasheets： | |
|---|---|
| VQB100R Series： | |
| Product Photos： | |
| VQB100R-T110-Sxx： | |
| Product Training Modules： | |
| Railway DC-DC Converters： | |
| EMI Regulations and Mitigation Considerations for Switching Power Supplies： | |
| Reliability Considerations for Power Supplies： | |
| Power Supply Safety Standards, Agencies and Marks： | |
| RoHS Information： | |
| VQB100R Series Cert of Compliance： | |
| Featured Product： | |
| CUI - VQB100R-T110/VHB150R-T110： | |
| CUI Railway DC-DC Converters： | |
| 3D Model： | |
| VQB100R-T110-S24： | |
| Standard Package ： | 48 |
| Category： | Power Supplies - Board Mount |
| Family： | DC DC Converters |
| Series： | VQB100R |
| Packaging ： | Bulk |
| Type： | Isolated Module |
| Number of Outputs： | 1 |
| Voltage - Input (Min)： | 66V |
| Voltage - Input (Max)： | 160V |
| Voltage - Output 1： | 24V |
| Voltage - Output 2： | - |
| Voltage - Output 3： | - |
| Current - Output (Max)： | 4.2A |
| Power (Watts) - Manufacture Series： | 100W |
| Voltage - Isolation： | 2.25kV (2250V) |
| Features： | Remote On/Off, OCP, OTP, OVP, SCP, UVLO |
| Mounting Type： | Through Hole |
| Package / Case： | 8-DIP Module, 1/4 Brick |
| Size / Dimension： | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) |
| Operating Temperature： | -40°C ~ 100°C |
| Efficiency： | 91% |
| Power (Watts) - Max： | 100W |
| Dynamic Catalog： | VQB100R Series |
| Other Names： | 102-2649VQB100RT110S24 |
