VHB75-D12-S3R3的详细信息
| Datasheets： | |
|---|---|
| VHB75 Series： | |
| Product Photos： | |
| VHB759-DIP SERIES： | |
| RoHS Information： | |
| VHB75-D12 Series Cert of Compliance： | |
| 3D Model： | |
| VHB75-D12-S3R3： | |
| Other Drawings： | |
| VHB50W, VHB75 Series Side： | |
| VHB Series Bottom： | |
| Standard Package ： | 48 |
| Category： | Power Supplies - Board Mount |
| Family： | DC DC Converters |
| Series： | VHB75 |
| Packaging ： | Bulk |
| Type： | Isolated Module |
| Number of Outputs： | 1 |
| Voltage - Input (Min)： | 9V |
| Voltage - Input (Max)： | 18V |
| Voltage - Output 1： | 3.3V |
| Voltage - Output 2： | - |
| Voltage - Output 3： | - |
| Current - Output (Max)： | 15A |
| Power (Watts) - Manufacture Series： | 75W |
| Voltage - Isolation： | 1.5kV (1500V) |
| Features： | Remote On/Off, OCP, OTP, OVP, SCP, UVLO |
| Mounting Type： | Through Hole |
| Package / Case： | 9-DIP Module, 1/2 Brick |
| Size / Dimension： | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) |
| Operating Temperature： | -40°C ~ 100°C |
| Efficiency： | 78% |
| Power (Watts) - Max： | 49.5W |
| Dynamic Catalog： | VHB75 Series |
| Associated Product： | 102-1489-ND - HEATSINK HALF BRICK ALUM BLACK102-1488-ND - HEATSINK HALF BRICK ALUM BLACK |
| Other Names： | 102-1255VHB75D12S3R3 |
