TPS23753APWR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Hot Swap Voltage Controllers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Product： | PoE / LAN Solutions |
| Current Limit： | 0.405 A |
| Supply Voltage - Max： | 57 V |
| Supply Voltage - Min： | 0 V |
| Operating Temperature Range： | - 40 C to + 125 C |
| Power Dissipation： | 13 W |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-14 |
| Packaging： | Reel |
| Series： | TPS23753A |
| Factory Pack Quantity： | 2000 |
TPS23753APWR相关文档
- Evaluation Kits: Class 3,Efficiency-Optimized, Flyback Converter for PoE Applications
- Evaluation Kits: 5Vout, 7W, IEEE 802.3-2005 Compliant, PD Controller, PS Controller EVM for TPS23753AEVM-001
- Evaluation Kits: Class 2- Low Cost 3.3V/1.8A Flyback Converter for PoE Applications
- Evaluation Kits: Isolated Flyback with synchronous bucks and boost (5V @ 1A)
- Evaluation Kits: IP Net Camera Power Module Reference Solution
- Evaluation Kits: Class 3- Low Cost 12V/1A Flyback Converter for PoE Applications
- Evaluation Kits: Class 3,Cost-Optimized,Flyback Converter for PoE Applications
- Evaluation Kits: Class 3- Isolated Flyback (15V@0.72A) for PoE Applications
- Evaluation Kits: 3.3Vout, 10W, IEEE 802.3-2005 Compliant PD Controller, PS Controller Evaluation Module for TPS23753A
- Function Diagram: alt_slvs933b
- Evaluation Kits: Class 3 - 5V/2.3A High Efficiency Synchronous Flyback Converter for PoE Application
TPS23753APWR应用笔记
- Practical Guidelines EMI Compliant PoE
- Designing an EMI Compliant PoE with Isolated Flyback
- PoE Powered Device for 24 VAC Building Power Applications
- Designing with the TPS23753 Powered Device and Power Supply Controller (Rev. C)
- Using the TPS23753A with an External Error Amplifier
- Advanced Adapter ORing Solutions using the TPS23753 (Rev. A)
- Implementing a Buck Converter With the TPS23753A
