| 型号： | TMS320F28234PGFA |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 集成电路 - IC |
| 描述： | digital signal processors & controllers - dsp, dsc dig signal cntrlr |
| 报错 收藏 赞 | |
TMS320F28234PGFA的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Digital Signal Processors & Controllers - DSP, DSC |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Core： | TMS320 |
| Data Bus Width： | 32 bit |
| Program Memory Size： | 256 kB |
| Data RAM Size： | 68 kB |
| Maximum Clock Frequency： | 150 MHz |
| Number of Programmable I/Os： | 88 |
| Number of Timers： | 3 |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | LQFP-176 |
| Mounting Style： | SMD/SMT |
| Core Architecture： | RISC |
| Family： | RISC |
| Family / Core： | C2000 |
| Instruction Type： | Fixed Point |
| Interface Type： | I2C, SCI, SPI, UART |
| Minimum Operating Temperature： | - 40 C |
| On-Chip ADC： | Yes |
| Processor Series： | TMS320F2x |
| Product： | DSCs |
| Program Memory Type： | Flash |
| Series： | TMS320F28234 |
| Factory Pack Quantity： | 40 |
| Supply Voltage - Min： | 1.805 V, 3.135 V |
| Tradename： | C2000 |
| Type： | C2000 |
| Unit Weight： | 1.896 g |
TMS320F28234PGFA相关文档
- Evaluation Kits: C2000 DC/DC Developer's Kit
- Evaluation Kits: TMS320F2833x Reference Design
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Reference Design: TMS320C28x DSP CPU and Instruction Set Reference Guide (Rev. E)
- Evaluation Kits: XDS200 Price/Performance-balanced Debug Probe
- Evaluation Kits: TMS320F28335 Experimenter Kit
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: C2000 Gang Programmer
- Function Diagram: fbd_sprs439m
TMS320F28234PGFA应用笔记
- Programming TMS320x28xx and 28xxx Peripherals in C/C++ (Rev. D)
- Getting Started With TMS320C28x Digital Signal Controllers (Rev. A)
- TPS75005 Quick-Start Guide with C2000? Controllers
- TMS320x2833x/2823x to TMS320x2834x Delfino Migration Overview
- Hardware Design Guidelines for TMS320F28xx and TMS320F28xxx DSCs (Rev. B)
- Online Stack Overflow Detection on the TMS320C28x DSP
- Programming External Nonvolatile Memory Using SDFlash for TMS320C28x Devices
- Common Object File Format (COFF)
- Running an Application from Internal Flash Memory on the TMS320F28xxx DSP (Rev. L)
- PowerPAD? Thermally Enhanced Package (Rev. G)
- TMS320x280x to TMS320x2833x or 2823x Migration Overview (Rev. B)
- Interfacing the TMS320F2833x to the AIC23B Stereo Audio Codec
- An Easy Way of Creating a C-callable Assembly Function for the TMS320C28x DSP
- TMS320x281x to TMS320x280x/2801x/2804x Migration Overview (Rev. A)
- Using the eQEP Module in TMS320x280x as a Dedicated Capture
- TMS320x281x to TMS320x2833x or 2823x Migration Overview (Rev. B)
- Using Enhanced Pulse Width Modulator (ePWM) Module for 0-100% Duty Cycle Control
- EEPROM Emulation With the TMS320F28xxx DSCs
- TMS320F280x DSC USB Connectivity Using TUSB3410 USB-to-UART Bridge Chip
- TMS320280x and TMS320F2801x ADC Calibration (Rev. A)
- Copying Compiler Sections from Flash to RAM on the TMS320F28xxx DSCs
- Flash Programming Solutions for the TMS320F28xxx DSCs
- Using PWM Output as a Digital-to-Analog Converter on a TMS320F280x (Rev. A)
