TLV431AIDBVRE4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Voltage References |
| RoHS： | Yes |
| Reference Type： | Shunt Adjustable Precision References |
| Output Voltage： | Adjustable |
| Initial Accuracy： | 1 % |
| Brand： | Texas Instruments |
| Average Temperature Coefficient - Typ： | 129 PPM / C |
| Series VREF - Input Voltage - Max： | 7 V |
| Shunt Current - Max： | 15 mA |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-5 |
| Packaging： | Reel |
| Minimum Operating Temperature： | - 40 C |
| Series： | TLV431A |
| Shunt Current - Min： | 80 uA |
| Factory Pack Quantity： | 3000 |
| Unit Weight： | 15.800 mg |
