TC1410EPA的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | Gate Drivers |
| RoHS： | Yes |
| Brand： | Microchip Technology |
| Product： | MOSFET Gate Drivers |
| Configuration： | Inverting |
| Number of Drivers： | 1 |
| Rise Time： | 35 ns |
| Fall Time： | 35 ns |
| Supply Voltage - Max： | 16 V |
| Supply Voltage - Min： | 4.5 V |
| Supply Current： | 1 mA |
| Maximum Power Dissipation： | 730 mW |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-8 |
| Type： | Low Side |
| Minimum Operating Temperature： | - 40 C |
| Number of Outputs： | 2 |
| Packaging： | Tube |
| Factory Pack Quantity： | 60 |
TC1410EPA相关文档
- Product Selection Tools: Analog & Interface Product Selector Guide
- Brochures: Analog & Interface Guide (Volume 2)
- User Guides: 8-Pin SOIC/MSOP/TSSOP/DIP Evaluation Board User's Guide
- Sample Code: SPICE Models for TC1410-10N MOSFET Driver Devices
- User Guides: Quick Guide to Microchip Development Tools
TC1410EPA应用笔记
- AN786 - Considerations for Driving Power MOSFETs in High-Current, Switch Mode Regulators
- AN1256 - Microchip's Power MOSFET Driver Simulation Models
- AN898 - Determining MOSFET Driver Needs for Motor Drive Applications
- 01327A - Avoiding MOSFET Driver Overstress
- DG9 - Analog Solutions for Automotive Applications Design Guide
- AN763 - Latch-Up Protection for MOSFET Drivers
- AN799 - Matching MOSFET Drivers to MOSFETs
