STMicroelectronics
STEVAL-ILL007V1的详细信息
| Datasheets： | |
|---|---|
| L5973D： | |
| L5970D： | |
| STEVAL-ILL007V1 Data Brief： | |
| Product Photos： | |
| STEVAL-ILL007V1： | |
| Design Resources： | |
| STEVAL-ILL007V1 BOM： | |
| STEVAL-ILL007V1 Gerber Files ： | |
| Reference Design Library： | |
| STEVAL-ILL007V1： | 1 to 3 LEDs @ 0.35, 0.7, or 1A |
| Standard Package ： | 1 |
| Category： | Programmers, Development Systems |
| Family： | Evaluation Boards - LED Drivers |
| Series： | - |
| Current - Output / Channel： | 350mA, 700mA, or 1.05A |
| Outputs and Type： | 1, Non-Isolated |
| Voltage - Output： | 35V |
| Features： | Thermal Shutdown Protection |
| Voltage - Input： | 12VAC, 6 V ~ 24 V |
| Supplied Contents： | Board |
| Utilized IC / Part： | L5973 |
| Associated Product： | 497-9055-ND - BOARD EVAL LED LB W55M497-8424-ND - BOARD EVAL OSRAM RED LA W55M497-8423-ND - BOARD EVAL OSRAM WM WHT LCW W5AM497-8422-ND - BOARD EVAL OSRAM WHITE LUW W5AM67-2054-ND - LED LIGHT ENGINE GREEN67-2053-ND - LED LIGHT ENGINE YELLOW67-2052-ND - LED LIGHT ENGINE BLUE67-2051-ND - LED LIGHT ENGINE RED67-2050-ND - LED LIGHT ENGINE WHITE |
| Other Names： | 497-5074 |
