SN74LS244N的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Buffers & Line Drivers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Input Lines： | 8 |
| Number of Output Lines： | 8 |
| Polarity： | Non-Inverting |
| Supply Voltage - Max： | 5.25 V |
| Supply Voltage - Min： | 4.75 V |
| Maximum Operating Temperature： | + 70 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-20 |
| Packaging： | Tube |
| High Level Output Current： | - 15 mA |
| Logic Family： | LS |
| Logic Type： | Bipolar |
| Low Level Output Current： | 24 mA |
| Minimum Operating Temperature： | 0 C |
| Number of Channels per Chip： | 8 |
| Output Type： | 3-State |
| Propagation Delay Time： | 18 ns at 5 V |
| Series： | SN74LS244 |
| Factory Pack Quantity： | 20 |
| Unit Weight： | 1.199 g |
SN74LS244N应用笔记
- Live Insertion
- TI IBIS File Creation, Validation, and Distribution Processes
- Designing with the SN54/74LS123 (Rev. A)
- Designing With Logic (Rev. C)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Input and Output Characteristics of Digital Integrated Circuits
