SN74CBTH16211DL的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Digital Bus Switch ICs |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Switches： | 24 |
| On Resistance - Max： | 7 Ohms |
| Propagation Delay Time： | 0.25 ns |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 4 V |
| Maximum Operating Temperature： | + 85 C |
| Minimum Operating Temperature： | - 40 C |
| Package / Case： | SSOP-56 |
| Packaging： | Tube |
| Logic Family： | CBT |
| Mounting Style： | SMD/SMT |
| Operating Temperature： | - 40 C to + 85 C |
| Series： | SN74CBTH16211 |
| Factory Pack Quantity： | 20 |
| Supply Current： | 3 uA |
| Technology： | CBT |
| Unit Weight： | 694.800 mg |
SN74CBTH16211DL应用笔记
- Selecting the Right Level Translation Solution (Rev. A)
- VOLTAGE LEVEL TRANSLATION (SL) - Family
- 5-V To 3.3-V Translation With the SN74CBTD3384 (Rev. B)
- TI IBIS File Creation, Validation, and Distribution Processes
- 16-Bit Widebus Logic Families in 56-Ball, 0.65-mm Pitch Very Thin Fine-Pitch BGA (Rev. B)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- How to Select Little Logic
- 3.3-V to 2.5-V Translation with Texas Instruments Crossbar Technology (Rev. A)
- Migration From 3.3-V To 2.5-V Power Supplies For Logic Devices
- Selecting the Right Texas Instruments Signal Switch
- Bus FET Switch Solutions for Live Insertion Applications
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Texas Instruments Little Logic Application Report
- Understanding Advanced Bus-Interface Products Design Guide
- Flexible Voltage-Level Translation With CBT Family Devices
