SN74CBT16232DLR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Multiplexer Switch ICs |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Switches： | 16 |
| On Resistance - Max： | 14 Ohms |
| Propagation Delay Time： | 0.35 ns at 4 V, 0.25 ns at 5 V |
| Operating Supply Voltage： | 4 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SSOP-56 |
| Minimum Operating Temperature： | - 40 C |
| Packaging： | Reel |
| Series： | SN74CBT16232 |
| Factory Pack Quantity： | 1000 |
| Unit Weight： | 694.800 mg |
SN74CBT16232DLR应用笔记
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Bus FET Switch Solutions for Live Insertion Applications
- Selecting the Right Texas Instruments Signal Switch
- Migration From 3.3-V To 2.5-V Power Supplies For Logic Devices
- Flexible Voltage-Level Translation With CBT Family Devices
- Understanding Advanced Bus-Interface Products Design Guide
- Texas Instruments Little Logic Application Report
- Selecting the Right Level Translation Solution (Rev. A)
- VOLTAGE LEVEL TRANSLATION (SL) - Family
- 16-Bit Widebus Logic Families in 56-Ball, 0.65-mm Pitch Very Thin Fine-Pitch BGA (Rev. B)
- 5-V To 3.3-V Translation With the SN74CBTD3384 (Rev. B)
- TI IBIS File Creation, Validation, and Distribution Processes
- Shelf-Life Evaluation of Lead-Free Component Finishes
- How to Select Little Logic
- 3.3-V to 2.5-V Translation with Texas Instruments Crossbar Technology (Rev. A)
- Implications of Slow or Floating CMOS Inputs (Rev. C)
