SMMBT2222ALT3G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | Transistors Bipolar - BJT |
| RoHS： | Yes |
| Configuration： | Single |
| Transistor Polarity： | NPN |
| Collector- Base Voltage VCBO： | 75 VDC |
| Collector- Emitter Voltage VCEO Max： | 40 V |
| Emitter- Base Voltage VEBO： | 6 V |
| Collector-Emitter Saturation Voltage： | 1 V |
| Maximum DC Collector Current： | 1100 mA |
| Gain Bandwidth Product fT： | 300 MHz |
| Maximum Operating Temperature： | + 150 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23 |
| Brand： | ON Semiconductor |
| Continuous Collector Current： | 600 mA |
| DC Collector/Base Gain hfe Min： | 40 |
| Maximum Power Dissipation： | 300 mW |
| Minimum Operating Temperature： | - 55 C |
| Packaging： | Reel |
| Series： | MMBT2222AL |
| Factory Pack Quantity： | 10000 |
SMMBT2222ALT3G相关文档
- PCN: ON Semiconductor - PCN 6-2-10
- PCN: On Semiconductor - PCN 5-21-10
- Package Drawing: SOT-23 (TO-236) 3 LEAD
- Simulation Model: LIB Model For MMBT2222ALT1
- Simulation Model: SP2 Model For MMBT2222ALT1
- Simulation Model: SIN Model For MMBT2222ALT1
- Simulation Model: SP3 Model For MMBT2222ALT1
