S-302-CCT的详细信息
| Datasheets： | |
|---|---|
| 300 Series, Plugs/Sockets： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Blade Type Power Connectors |
| Series： | 300 |
| Packaging ： | Bulk |
| Connector Style： | - |
| Connector Type： | Socket, Jones |
| Number of Positions： | 2 |
| Pitch： | - |
| Mounting Type： | Free Hanging (In-Line) |
| Number of Rows： | 1 |
| Row Spacing： | - |
| Termination： | Solder Eyelet(s) |
| Wire Gauge： | - |
| Features： | Hood, Cable Clamp |
| Color： | Black |
| Fastening Type： | Push-Pull |
| Contact Material： | Phosphor Bronze |
| Contact Finish： | Cadmium |
| Contact Finish Thickness： | - |
| Voltage Rating： | 250V |
| Current Rating： | 10A |
| Material - Insulation： | Phenol Formaldehyde (Phenolic) |
| Operating Temperature： | 105°C |
| Mating Products： | 116-1031-ND - CONN PLUG 2POS IN-LINE SLDRP-302H-AB-ND - CONN PLUG 2POS PNL MNT SLDRCJ102P-ND - CONN PLUG 2POS IN-LINE SLDR |
| Other Names： | CJ102SS-302-CCT-PS302CCTS302CCT-PSJ102S |
