| 型号： | RV4NAYSD752A |
| 厂商： |
Precision Electronic Components Ltd |
| 标准： |   |
| 分类： | 半导体 ， 旋转式电位计 - 线性 |
| 描述： | pot 7.5K ohm carbon 2 watt |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 第三方平台下载 >> |
RV4NAYSD752A的详细信息
| Datasheets： | |
|---|---|
| MIL Style RV4, Precision Series K： | |
| Product Photos： | |
| RV4N Series： | |
| Catalog Drawings： | |
| RV4, K(K)(A,B,U) Series Side： | |
| RV4N,K(A,B,U) Series Side： | |
| Standard Package ： | 1 |
| Category： | Potentiometers, Variable Resistors |
| Family： | Rotary Potentiometers - Linear |
| Series： | MIL-R-94, RV4 |
| Packaging ： | Bulk |
| Resistance (Ohms)： | 7.5k |
| Power (Watts)： | 2W |
| Tolerance： | ±10% |
| Temperature Coefficient： | - |
| Number of Turns： | Single |
| Rotation： | 314° |
| Adjustment Type： | Side Adjustment |
| Resistive Material： | Carbon |
| Termination Style： | Solder Lug |
| Actuator Length： | 0.875" (22.22mm) |
| Actuator Type： | Slotted Shaft |
| Actuator Diameter： | 0.249" (6.32mm) |
| Size - Body： | Round - 1.120" Dia x 0.536" L (28.45mm x 13.61mm) |
| Mounting Type： | Panel Mount |
| Dynamic Catalog： | MIL-R-94, RV4N Series |
