RJH60D2DPP-M0#T2的详细信息
| Datasheets： | |
|---|---|
| RJH60D2DPP-M0： | |
| Product Photos： | |
| TO-220AB： | |
| Standard Package ： | 1 |
| Category： | Discrete Semiconductor Products |
| Family： | IGBTs - Single |
| Series： | - |
| Packaging ： | Tube |
| IGBT Type： | Trench |
| Voltage - Collector Emitter Breakdown (Max)： | 600V |
| Current - Collector (Ic) (Max)： | 25A |
| Current - Collector Pulsed (Icm)： | - |
| Vce(on) (Max) @ Vge, Ic： | 2.2V @ 15V, 12A |
| Power - Max： | 34W |
| Switching Energy： | 100µJ (on), 160µJ (off) |
| Input Type： | Standard |
| Gate Charge： | 19nC |
| Td (on/off) @ 25°C： | 32ns/85ns |
| Test Condition： | 300V, 12A, 5 Ohm, 15V |
| Reverse Recovery Time (trr)： | 100ns |
| Package / Case： | TO-220-3 Full Pack |
| Mounting Type： | Through Hole |
| Supplier Device Package： | TO-220FL |
| Dynamic Catalog： | Standard IGBTs |
