R87T-A1A15HP的详细信息
| Datasheets： | |
|---|---|
| R87F/R87T： | |
| Other Related Documents： | |
| How to Read Date Codes： | |
| Standard Package ： | 1 |
| Category： | Fans, Thermal Management |
| Family： | AC Fans |
| Series： | R87T |
| Voltage - Rated： | 100VAC |
| Size / Dimension： | Square - 120mm L x 120mm H x 38mm W |
| Air Flow： | 106.0 CFM (3.00m³/min) |
| Static Pressure： | 0.236 in H2O (58.8 Pa) |
| Bearing Type： | Ball |
| Fan Type： | Tubeaxial |
| Features： | - |
| Noise： | 46 dB |
| Power (Watts)： | 18.0W |
| RPM： | 3100 RPM |
| Termination： | 2 Terminals |
| Ingress Protection： | - |
| Weight： | 1.3 lbs (589.7g) |
| Operating Temperature： | -4 ~ 158°F (-20 ~ 70°C) |
| Current Rating： | 0.210A |
| Life Expectancy： | - |
| Voltage Range： | - |
| Material - Frame： | Aluminum |
| Material - Blade： | Zinc |
| Associated Product： | R87F-PC-20-ND - PLUG CORD 250V 3A 2M FOR R87 FANZ3563-ND - PLUG CORD 250V 3A 1M FOR R87 FANR87F-FL120S-ND - FILTER SCREEN FOR 120MM FANSR87F-FL120-ND - FILTER PLASTIC FOR 120MM FANSR87F-FG120-ND - GRILL GUARD FOR 120MM FANSQ837-ND - POWER CORD FAN T-TYPE 40"07100-60-ND - POWER CORD FAN STRAIGHT 60"07100-40-ND - POWER CORD FAN STRAIGHT 40"Q836-ND - POWER CORD FAN RIGHT ANGLE 80"07190-60-ND - POWER CORD FAN RIGHT ANGLE 60"07190-50-ND - POWER CORD FAN RIGHT ANGLE 50"07190-40-ND - POWER CORD FAN RIGHT ANGLE 40"07145-80-ND - POWER CORD FAN 45DEG ANGLE 80"07145-60-ND - POWER CORD FAN 45DEG ANGLE 60"07145-50-ND - POWER CORD FAN 45DEG ANGLE 50"07145-40-ND - POWER CORD FAN 45DEG ANGLE 40"CR372-ND - POWER CORD W/PLUG FAN T-TYPE 72"CR371-ND - POWER CORD W/PLUG FAN T-TYPE 36"CR370-ND - POWER CORD W/PLUG FAN T-TYPE 24"CR369-ND - POWER CORD W/PLUG FAN R/A 72"CR368-ND - POWER CORD W/PLUG FAN R/A 36"CR367-ND - POWER CORD W/PLUG FAN R/A 24"CR366-ND - POWER CORD W/PLUG FAN 45DEG 72"CR365-ND - POWER CORD W/PLUG FAN 45DEG 36"CR364-ND - POWER CORD W/PLUG FAN 45DEG 24"CR363-ND - POWER CORD W/PLUG STRAIGHT 72"CR362-ND - POWER CORD W/PLUG STRAIGHT 36"CR361-ND - POWER CORD W/PLUG STRAIGHT 24"CR338-ND - POWER CORD FAN T-TYPE 96"CR337-ND - POWER CORD FAN T-TYPE 72"CR336-ND - POWER CORD FAN STRAIGHT 72"CR323-ND - POWER CORD FAN T-TYPE 12"CR322-ND - POWER CORD FAN RIGHT AN |
