PVB3-D12-D12-D的详细信息
| Datasheets： | |
|---|---|
| PVB3-D Series： | |
| Product Photos： | |
| PVB3-D： | |
| Product Training Modules： | |
| Low Power DC-DC Converters： | |
| EMI Regulations and Mitigation Considerations for Switching Power Supplies： | |
| Reliability Considerations for Power Supplies： | |
| Power Supply Safety Standards, Agencies and Marks： | |
| RoHS Information： | |
| PUZ3-D Series Cert of Compliance： | |
| 3D Model： | |
| PVB3-D12-D12-D： | |
| Standard Package ： | 15 |
| Category： | Power Supplies - Board Mount |
| Family： | DC DC Converters |
| Series： | PVB3-D |
| Packaging ： | Tube |
| Type： | Isolated Module |
| Number of Outputs： | 2 |
| Voltage - Input (Min)： | 9V |
| Voltage - Input (Max)： | 18V |
| Voltage - Output 1： | 12V |
| Voltage - Output 2： | -12V |
| Voltage - Output 3： | - |
| Current - Output (Max)： | 125mA, 125mA |
| Power (Watts) - Manufacture Series： | 3W |
| Voltage - Isolation： | 3kV (3000V) |
| Features： | OCP, SCP |
| Mounting Type： | Through Hole |
| Package / Case： | 24-DIP Module (10 Leads) |
| Size / Dimension： | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) |
| Operating Temperature： | -40°C ~ 105°C |
| Efficiency： | 81% |
| Power (Watts) - Max： | 3W |
| Dynamic Catalog： | PVB3-D Series |
| Other Names： | 102-2865PVB3D12D12D |
