PSMN5R0-100PS,127的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 100 V |
| Vgs - Gate-Source Breakdown Voltage： | 20 V |
| Id - Continuous Drain Current： | 110 A |
| Rds On - Drain-Source Resistance： | 5 mOhms |
| Vgs th - Gate-Source Threshold Voltage： | 3 V |
| Qg - Gate Charge： | 170 nC |
| Maximum Operating Temperature： | + 175 C |
| Pd - Power Dissipation： | 338 W |
| Mounting Style： | Through Hole |
| Package / Case： | TO-220-3 |
| Packaging： | Tube |
| Brand： | NXP Semiconductors |
| Minimum Operating Temperature： | - 55 C |
| Factory Pack Quantity： | 50 |
PSMN5R0-100PS,127相关文档
- PCN: Advance Product Change Notification
- SPICE model: PSMN5R0_100PS Spice Model (v.1.0)
- Application note: Understanding Power MOSFET Datasheet Parameters (v.1.0)
- Selection guide: NXP's Power MOSFET Selection Guide 2012; Smaller, faster, cooler (v.2.1)
- Thermal model: PSMN5R0-100PS Thermal model (v.1.0)
- PCN: Customer Information Notification
- PCN: Final Product Change Notification
