PN14-6R-E的详细信息
| Standard Package ： | 20 |
|---|---|
| Category： | Connectors, Interconnects |
| Family： | Terminals - Ring Connectors |
| Series： | Pan-Term® |
| Packaging ： | Bulk |
| Terminal Type： | Circular |
| Stud/Tab Size： | 6 Stud |
| Thickness： | 0.031" (0.79mm) |
| Width - Outer Edges： | 0.310" (7.87mm) |
| Length - Overall： | 0.850" (21.59mm) |
| Mounting Type： | Free Hanging (In-Line) |
| Termination： | Crimp |
| Wire Gauge： | 14-16 AWG |
| Insulation： | Insulated |
| Features： | Serrated Termination |
| Color： | Blue |
| Contact Material： | Copper |
| Contact Finish： | Tin |
| Insulation Diameter： | 0.080" ~ 0.162" (2.03mm ~ 4.11mm) |
| Material - Insulation： | Polyamide (PA), Nylon |
| Associated Product： | CT-550CH-ND - TOOL CRIMP HEAD FOR CT-600-ACT-500CH-ND - TOOL CRIMP HEAD FOR CT-600-ACT-460-ND - TOOL CRIMP INS TERM 10-16AWGCT-400-ND - TOOL CRIMP INS TERM 14-22AWGCT-1551-ND - TOOL CRIMP INS TERM CONT-CYCLE298-1380-ND - TOOL CRIMP INS TERM CONT-CYCLECT-100-ND - TOOL CRIMPER PLIER #26-#10 SCREW |
| Other Names： | 07498336555 |
