PIC18F8621-I/PT的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | PIC |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 40 MHz |
| Program Memory Size： | 64 kB |
| Data RAM Size： | 3840 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 4.2 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | TQFP-80 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 16 |
| Brand： | Microchip Technology |
| Data ROM Size： | 1024 B |
| Data ROM Type： | EEPROM |
| Interface Type： | EUSART, I2C, MSSP, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 69 |
| Number of Timers： | 5 |
| Packaging： | Tray |
| Processor Series： | PIC18 |
| Program Memory Type： | Flash |
| Series： | PIC18 |
| Factory Pack Quantity： | 119 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 4.2 V |
PIC18F8621-I/PT相关文档
- Product Selection Tools: Corporate Product Selector Guide
- Sell Sheets: MPLAB® X IDE Product Overview
- Sell Sheets: Choose PIC MCUs
- Sell Sheets: HI-TECH C Compilers by Microchip Technology
- Tips and Tricks: PIC Microcontroller Compiled Tips 'n Tricks Guide
- Programming Specifications: PIC18F6X2X/8X2X FLASH Microcontroller Programming Specification
- Migration Documents: PIC18F to PIC24F Migration: An Overview
- Migration Documents: Migrating from PIC18F to PIC18FXXJ Flash Devices
- Errata: PIC18F6525/6621/8525/8621 Rev. A1 Silicon/ Datasheet Errata
- Brochures: 8-bit PIC® Microcontroller Solutions
- Errata: Timer1 Module Data Sheet Errata
PIC18F8621-I/PT应用笔记
- AN1204 - Microchip MiWi P2P Wireless Protocol
- AN851 - A FLASH Bootloader for PIC16 and PIC18 Devices
- AN937 - Implementing a PID Controller Using a PIC18 MCU
- AN833 - Microchip TCP/IP Stack Application Note
- AN870 - An SNMP Agent for the Microchip TCP/IP Stack
- AN1066 - MiWi Wireless Networking Protocol Stack
- AN914 - Dynamic Memory Allocation for the MPLAB® C18 C Compiler
- AN953 - Data Encryption Routines for PIC18 Microcontrollers
- AN778 - Implementing the External Memory Interface on PIC18C601/801 Appication Note
- AN1095 - AN1095, Emulating Data EEPROM for PIC18 and PIC24 MCUs and dsPIC DSCs
- AN1310 - High-Speed Bootloader for PIC16 and PIC18 Devices
- AN1229 - Class B Safety Software Library for PIC MCUs and dsPIC DSCs
- AN869 - External Memory Interfacing Techniques for the PIC18F8XXX
