PIC18F2539-I/SO的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | PIC |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 40 MHz |
| Program Memory Size： | 24 kB |
| Data RAM Size： | 1408 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | SOIC-28 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 5 |
| Brand： | Microchip Technology |
| Data ROM Size： | 256 B |
| Data ROM Type： | EEPROM |
| Interface Type： | AUSART, I2C, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 21 |
| Number of Timers： | 16 bit |
| Packaging： | Tube |
| Processor Series： | PIC18 |
| Program Memory Type： | Flash |
| Series： | PIC18 |
| Factory Pack Quantity： | 27 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 4.2 V |
PIC18F2539-I/SO相关文档
- Sell Sheets: HI-TECH C Compilers by Microchip Technology
- Brochures: 8-bit PIC® Microcontroller Solutions
- Migration Documents: PIC18F to PIC24F Migration: An Overview
- Errata: Timer1 Module Data Sheet Errata
- Tips and Tricks: PIC Microcontroller Compiled Tips 'n Tricks Guide
- Errata: PIC18FXX39 Rev. B5 Silicon Errata
- Migration Documents: Migrating from PIC18F to PIC18FXXJ Flash Devices
- Product Selection Tools: Corporate Product Selector Guide
- Programming Specifications: Programming Specifications for PIC18FXX39 FLASH MCUs
- Product Line Documents: PIC18XXXX MCU Family Product Overview
- Sell Sheets: Choose PIC MCUs
- User Guides: MPLAB IDE PICSTART Plus User's Guide
- Sell Sheets: MPLAB® X IDE Product Overview
PIC18F2539-I/SO应用笔记
- AN1204 - Microchip MiWi P2P Wireless Protocol
- AN851 - A FLASH Bootloader for PIC16 and PIC18 Devices
- AN1095 - AN1095, Emulating Data EEPROM for PIC18 and PIC24 MCUs and dsPIC DSCs
- AN861 - Smart Air Handler using ProMPT™ and the PIC18F2539
- AN1066 - MiWi Wireless Networking Protocol Stack
- AN1310 - High-Speed Bootloader for PIC16 and PIC18 Devices
- AN914 - Dynamic Memory Allocation for the MPLAB® C18 C Compiler
- AN953 - Data Encryption Routines for PIC18 Microcontrollers
- AN1229 - Class B Safety Software Library for PIC MCUs and dsPIC DSCs
