PIC16F913-I/SP的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | PIC |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 20 MHz |
| Program Memory Size： | 7 kB |
| Data RAM Size： | 256 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | SPDIP-28 |
| Mounting Style： | Through Hole |
| A/D Channels Available： | 8 |
| Brand： | Microchip Technology |
| Data RAM Type： | RAM |
| Data ROM Size： | 256 B |
| Data ROM Type： | EEPROM |
| Interface Type： | AUSART, I2C, SPI, SSP |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 35 |
| Number of Timers： | 3 |
| On-Chip DAC： | No |
| Packaging： | Tube |
| Processor Series： | PIC16 |
| Program Memory Type： | Flash |
| Series： | PIC16 |
| Factory Pack Quantity： | 15 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2 V |
PIC16F913-I/SP相关文档
- Tips and Tricks: LCD PICmicro MCU Tips 'n Tricks
- Brochures: 8-bit PIC® Microcontroller Solutions
- Brochures: START NOW with Small Flash PIC® Microcontrollers
- Sell Sheets: MPLAB® X IDE Product Overview
- User Guides: PICDEM LCD Demonstration Kit User's Guide
- Errata: PIC16F91X/946 Family Silicon Errata and Data Sheet Clarification
- Programming Specifications: PIC16F91X/946 Memory Programming Specification
- User Guides: PICDEM LCD 2 Demonstration Kit User's Guide
- Brochures: Solutions for Medical Applications
- Sell Sheets: Choose PIC MCUs
- Errata: Timer1 Module Data Sheet Errata
- Product Selection Tools: Corporate Product Selector Guide
- Brochures: PICDEM LCD Brochure
- Tips and Tricks: PIC Microcontroller Compiled Tips 'n Tricks Guide
- Technical Briefs: Contrast Control Circuits for the PIC16F91X
- Sell Sheets: PICkit 2 Starter Kit Product Overview
PIC16F913-I/SP应用笔记
- AN736 - An I2C Network Protocol for Environmental Monitoring
- AN1229 - Class B Safety Software Library for PIC MCUs and dsPIC DSCs
- AN1066 - MiWi Wireless Networking Protocol Stack
- AN734 - Using the PIC Devices' SSP and MSSP Modules for Slave I2C Communication
- AN1310 - High-Speed Bootloader for PIC16 and PIC18 Devices
- AN1013 - Gas and Water Metering with the PIC16F91X Family
