PIC16F676-E/ST的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | PIC |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 20 MHz |
| Program Memory Size： | 1.75 kB |
| Data RAM Size： | 64 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2 V to 5.5 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | TSSOP-14 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 8 |
| Brand： | Microchip Technology |
| Data RAM Type： | SRAM |
| Data ROM Size： | 128 B |
| Data ROM Type： | EEPROM |
| Interface Type： | RS-232, USB |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 12 |
| Number of Timers： | 2 |
| On-Chip DAC： | No |
| Packaging： | Tube |
| Processor Series： | PIC16 |
| Program Memory Type： | Flash |
| Series： | PIC16 |
| Factory Pack Quantity： | 96 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2 V |
