PF0698.105NLT的详细信息
Datasheets: | |
---|---|
PF0698NL Series: | |
Standard Package : | 280 |
Category: | Inductors, Coils, Chokes |
Family: | Fixed Inductors |
Series: | PF0698NL |
Packaging : | Tape & Reel (TR) |
Type: | Wirewound |
Material - Core: | - |
Inductance: | 1mH |
Tolerance: | ±20% |
Current Rating: | 490mA |
Current - Saturation: | 850mA |
Shielding: | Unshielded |
DC Resistance (DCR): | 2 Ohm Max |
Q @ Freq: | - |
Frequency - Self Resonant: | 1.2MHz |
Operating Temperature: | -40°C ~ 125°C |
Frequency - Test: | - |
Mounting Type: | Surface Mount |
Package / Case: | Non Standard |
Size / Dimension: | 0.510" L x 0.370" W (12.95mm x 9.40mm) |
Height - Seated (Max): | 0.445" (11.30mm) |
Supplier Device Package: | - |
