PCA9530DP,118的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | LED Lighting Drivers |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Input Voltage： | 2.3 V to 5.5 V |
| Maximum Supply Current： | 500 uA |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-8 |
| Low Level Output Current： | 6.5 mA |
| Minimum Operating Temperature： | - 40 C |
| Packaging： | Reel |
| Power Dissipation： | 400 mW |
| Factory Pack Quantity： | 2500 |
| Part # Aliases： | PCA9530DP-T |
PCA9530DP,118相关文档
- Leaflet: LED dimming with GPIO expansion; NXP 2/4/8/16-bit I2C/SMBus LED dimmers PCA9530/31/32/33 (v.1.0)
- Other type: Application guide: Set-top boxes (STBs) (v.1.0)
- User manual: I2C Demonstration Board 2005-1 Quick Start Guide (v.1.0)
- Application note: Level shifting techniques in I2C-bus design (v.1.0)
- Leaflet: Easily test and demonstrate the PCA9698 40-bit GPIO; NXP PCA9698 daughter card OM6281 (v.1.0)
- User manual: I2C-bus specification and user manual (v.4.0)
- User manual: PCA9633 demonstration board OM6282 (v.1.0)
- User manual: PCA9698 demonstration board OM6281 (v.1.0)
- Application note: A guide to designing for ESD and EMC (v.2.0)
- Leaflet: I2C Selection Guide 2H 2011 (v.1.0)
- Brochure: Create smarter, more efficient white goods; An industry-leading portfolio of cost-effective, power-saving solutions for major home appliances (v.1.0)
- PCN: Customer Information Notification
