OZ-SS-112D,200的详细信息
| Datasheets： | |
|---|---|
| OZ-T Drawing： | |
| 3D Model： | |
| OZ-SS-112D,200.pdf： | |
| Standard Package ： | 300 |
| Category： | Relays |
| Family： | Power Relays, Over 2 Amps |
| Series： | OZ, OEG |
| Packaging ： | Bulk |
| Relay Type： | General Purpose |
| Coil Type： | Non Latching |
| Coil Current： | 60mA |
| Coil Voltage： | 12VDC |
| Contact Form： | SPDT (1 Form C) |
| Contact Rating (Current)： | 16A |
| Switching Voltage： | 240VAC, 24VDC - Max |
| Turn On Voltage (Max)： | 8.4 VDC |
| Turn Off Voltage (Min)： | 0.6 VDC |
| Operate Time： | 15ms |
| Release Time： | 8ms |
| Features： | Insulation - Class A, Sealed - Flux Protection |
| Mounting Type： | Through Hole |
| Termination Style： | PC Pin |
| Contact Material： | Silver Cadmium Oxide (AgCdO) |
| Coil Power： | 720 mW |
| Coil Resistance： | 200 Ohms |
| Operating Temperature： | -30°C ~ 55°C |
| Other Names： | 2-1440002-1 |
