OPA314AIDBVT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Operational Amplifiers - Op Amps |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Gain Bandwidth Product： | 3 MHz |
| Number of Channels： | 1 Channel |
| Common Mode Rejection Ratio - Min： | 75 dB |
| Input Offset Voltage： | 2.5 mV |
| Input Bias Current - Max： | 10 pA |
| Operating Supply Voltage： | 1.8 V to 5.5 V |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-5 |
| Slew Rate： | 1.5 V/us |
| Shutdown： | No Shutdown |
| Output Current： | 20 mA |
| Maximum Operating Temperature： | + 125 C |
| Packaging： | Reel |
| Minimum Operating Temperature： | - 40 C |
| Series： | OPA314 |
| Factory Pack Quantity： | 250 |
| Supply Current： | 150 uA |
OPA314AIDBVT相关文档
- SPICE Model: OPA314 TINA-TI Spice Model
- TINA Reference Design: OPA314 TINA-TI Reference Design
- Evaluation Kits: Single-Ended Input to Differential Output Conversion Circuit Reference Design
- Evaluation Kits: Universal Operational Amplifier Evaluation Module
- Function Diagram: alt_sbos563f
