OPA227UA/2K5的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Operational Amplifiers - Op Amps |
| RoHS： | Yes |
| Amplifier Type： | Low Noise Amplifier |
| Gain Bandwidth Product： | 8 MHz |
| Number of Channels： | 1 Channel |
| Common Mode Rejection Ratio - Min： | 120 dB |
| Input Offset Voltage： | 200 uV |
| Input Bias Current - Max： | 10 nA |
| Operating Supply Voltage： | 5 V to 36 V, +/- 2.5 V to +/- 18 V |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOIC-8 |
| Slew Rate： | 2.3 V/us |
| Shutdown： | No Shutdown |
| Output Current： | 45 mA |
| Maximum Operating Temperature： | + 85 C |
| Packaging： | Reel |
| Brand： | Texas Instruments |
| Dual Supply Voltage： | +/- 3 V, +/- 5 V, +/- 9 V |
| Input Referred Voltage Noise： | 3.5 nV |
| Maximum Dual Supply Voltage： | +/- 18 V |
| Minimum Dual Supply Voltage： | +/- 2.5 V |
| Minimum Operating Temperature： | - 40 C |
| Series： | OPA227 |
| Factory Pack Quantity： | 2500 |
| Supply Current： | 3.8 mA |
| Technology： | Bipolar |
| Unit Weight： | 76 mg |
OPA227UA/2K5相关文档
- PCN: Transfer of select devices in the BiPolar process node to SH-BIP-1 Facility
- TINA Reference Design: OPA227 TINA-TI Reference Design (Rev. A)
- SPICE Model: OPA227 TINA-TI Spice Model
- SPICE Model: OPAy227 PSpice Model (Rev. A)
OPA227UA/2K5应用笔记
- Optoelectronics Circuit Collection
- AB-174: Getting the Full Potential from your ADC (Rev. A)
- Tuning in Amplifiers
- A Numerical Protection Relay Solution
- Single-Supply Operation of Operational Amplifiers
- Op Amp Performance Analysis
- Shelf-Life Evaluation of Lead-Free Component Finishes
- OPA227, OPA2227, OPA4227, OPA228, OPA2228, OPA4228 EMI Immunity Performance (Rev. A)
- Topology and Noise Using Multiplying DACs
