型号:

NP90N04MUK-S18-AY

厂商: Renesas Electronics America
标准:
分类: 半导体FET - 单
描述: mosfet N-CH 40v 90a TO-220
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

NP90N04MUK-S18-AY的详细信息

Datasheets:
NP90N04MUK, NP90N04NUK:
Standard Package : 50
Category: Discrete Semiconductor Products
Family: FETs - Single
Series: -
Packaging : Tube
FET Type: MOSFET N-Channel, Metal Oxide
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 90A (Tc)
Rds On (Max) @ Id, Vgs: 2.8 mOhm @ 45A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) @ Vgs: 120nC @ 10V
Input Capacitance (Ciss) @ Vds: 7050pF @ 25V
Power - Max: 1.8W
Mounting Type: Through Hole
Package / Case: TO-220-3 Full Pack
Supplier Device Package: TO-220
