N3428-6305EB的详细信息
| Datasheets： | |
|---|---|
| 3000 Series Four-Wall Header： | |
| Short Form Catalog： | |
| Product Training Modules： | |
| IDC Wiremount Connectors Primer： | |
| Standard Package ： | 100 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular Connectors - Headers, Male Pins |
| Series： | 3000 |
| Packaging ： | Bulk |
| Contact Type： | Male Pin |
| Connector Type： | Header, Shrouded |
| Number of Positions： | 20 |
| Number of Positions Loaded： | All |
| Pitch： | 0.100" (2.54mm) |
| Number of Rows： | 2 |
| Row Spacing： | 0.100" (2.54mm) |
| Contact Mating Length： | 0.240" (6.10mm) |
| Mounting Type： | Through Hole |
| Termination： | Wire Wrap |
| Fastening Type： | Latch, Long/Eject Hooks |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Color： | Black |
| Mating Products： | 3M11966-ND - CONN SOCKET 20 POS IDC W/STR RELMKC20E-ND - CONN 20POS IDC SOCKET 10AU W/POLMSC20E-ND - CONN 20POS IDC SOCKET 10GOLD3M11977-ND - CONN 20POS IDC SOCKET GOLD W/POLD89120-0001HK-ND - CONN 20POS IDC SOCKET GOLDMSPV20-ND - CONN SOCKET PCB VERT 20POS .1"3M9099-ND - CONN RECEPT IDC 20POS 24-22 AWG3M9098-ND - CONN RECEPT IDC 20POS 28-26 AWG3M9097-ND - CONN RECEPT IDC 20POS 24-22 AWG3M9096-ND - CONN RECEPT IDC 20POS 28-26 AWG9120-4500PL-ND - CONN SOCKET 20POS .100" STR GOLD89120-0111-ND - CONN SOCKET 20POS IDC DL POL89120-0101HA-ND - CONN SOCKET 20POS IDC DL POL89120-0001HA-ND - CONN SOCKET 20POS IDC DUAL GOLD3M15468-ND - CONN SOCKET 20POS CLOSE END 3OAU3M11942-ND - CONN SOCKET 20POS CLOSE END 3OAU3M11941-ND - CONN SOCKET 20POS CLOSE END 30AU3M11940-ND - CONN SOCKET 20POS OPEN END 30AU3421-6020-ND - CONN SOCKET 20POS OPEN END 30AUMKC20A-ND - CONN 20 POS IDC SOCKET GOLD POLMSC20A-ND - CONN 20 POS IDC SOCKET GOLDMSD20K-ND - SOCKET CONN 20 CONT CLOSED W/POLMKC20K-ND - SOCK CONN 20 CONT OPEN W/POL GLDMSC20K-ND - SOCKET CONN 20 CONTACT OPEN GOLD |
| Associated Product： | 3448-2020-ND - CONN STRAIN RELIEF 20POS METALMHA102-ND - HEXHEAD BOLT NUT WASHER 2-56X1/23341-6-ND - HEXHEAD BOLT NUT WASHER 2-56X1/2MHA101-ND - SCREW PANHEAD THRD CUT 4-24X5/16 |
| Other Names： | 0511116538880400029817 |
