Freescale Semiconductor
MC9S08SH4MTJ的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | S08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 40 MHz |
| Program Memory Size： | 4 kB |
| Data RAM Size： | 256 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2.7 V to 5.5 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | TSSOP-20 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 12 |
| Brand： | Freescale Semiconductor |
| Interface Type： | I2C, SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 17 |
| Number of Timers： | 3 |
| Packaging： | Tube |
| Processor Series： | MC9S08 |
| Program Memory Type： | Flash |
| Series： | S08SH |
| Factory Pack Quantity： | 75 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
| Unit Weight： | 81.400 mg |
MC9S08SH4MTJ相关文档
- Errata: MSE9S08SH8_2M84G
- Package Description: TSSOP 20 4.4*6.5*1.P.65
- BlockDiagramLarge:
- Errata: MSE9S08SH32_1M07J
- Fact Sheets: SH32FS
- Quick Reference Guides: DEMO9S08SH8/SG8_QSG
- BlockDiagramSmall:
- Material Composition Declaration (MCD): IPC-1752 Report
- Datasheet: MC9S08SH32
- Errata: MSE9S08SH8_0M84G
- Datasheet: MC9S08SH8
- Fact Sheets: MC9S08SH84FS
- Users Guides: DEMO9S08SH8/SG8
- PCN: Product And Process Change Notification
- PCN: Copper Wire Conversion for Microcontroller and Microprocessor Devices
