MC9S08QD4CSCR的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | S08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 8 MHz |
| Program Memory Size： | 4 kB |
| Data RAM Size： | 256 B |
| On-Chip ADC： | Yes |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | SOIC-8 Narrow |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 4 |
| Brand： | Freescale Semiconductor |
| Interface Type： | I2C, SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 4 |
| Number of Timers： | 3 |
| Packaging： | Reel |
| Processor Series： | MC9S08 |
| Program Memory Type： | Flash |
| Series： | S08QD |
| Factory Pack Quantity： | 2500 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
| Unit Weight： | 74.150 mg |
MC9S08QD4CSCR相关文档
- Roadmap: 8BITAUTOROADMAP
- Errata: MSEF51QE128_1M12J
- Errata: MSE9S08QD4_1M15D
- Users Guides: HCS08QRUG
- Application Notes Software: AN3031SW.ZIP
- Reference Manuals: DRM088
- Users Guides: HCS08QRUGSW
- Brochures: 8BITFTPRNTCARD
- Reports or Presentations: 8-BIT AUTO_S08_FEATURE_BENEFITS
- White Papers: QD4DCFAN
- Brochures: BR8BITAUTOS08
- Reference Manuals: DRM101
- Application Notes Software: AN3414SW
- Fact Sheets: MC9S08QD4FS
- Reference Manuals: DRM086
- Reports or Presentations: 8-BIT AUTO_S08_CUSTOMER_BENEFITS
- Errata: MSE9S08QD4_0M15D
- Material Composition Declaration (MCD): IPC-1752 Report
- Fact Sheets: ZSTARBOARDFS
- Datasheet: MC9S08QD4
- Brochures: BRMECHATRONICS
- Package Description: SOIC 8
- Brochures: BRFSLSFWTLAUTO
- Fact Sheets: MC9S08QG84FS
- White Papers: QE128SWITCHWP
- Errata: DE0003
- Fact Sheets: S08QD4AUTOFS
- Application Notes Software: AN3381SW
- PCN: PRODUCT AND PROCESS CHANGE NOTIFICATION
- PCN: Copper Wire Conversion for Microcontroller and Microprocessor Devices
