LPC1343FBD48,151的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Core： | ARM Cortex M3 |
| Data Bus Width： | 32 bit |
| Maximum Clock Frequency： | 72 MHz |
| Program Memory Size： | 32 kB |
| Data RAM Size： | 8 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 3.3 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | LQFP-48 |
| Mounting Style： | SMD/SMT |
| Data RAM Type： | SRAM |
| Interface Type： | I2C, UART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 42 |
| Number of Timers： | 4 |
| Packaging： | Tray |
| Processor Series： | LPC13 |
| Program Memory Type： | Flash |
| Factory Pack Quantity： | 250 |
| Tradename： | LPC |
LPC1343FBD48,151相关文档
- Application note: AN10904 - LPC1300 USB HID (v.1.0)
- Application note: AN10973 - Using the LPC13xx low power modes and wake-up times on the LPCXpresso (v.1.0)
- Errata sheet: Errata sheet LPC1342/43 (v.6.0)
- Application note: Using the LPC13xx low power modes and wake-up times on the LPCXpresso (v.2.0)
- Software: AN11008 - Flash based non-volatile storage (v.1.0)
- Brochure: Cortex-M microcontroller brochure (v.2.0)
- Application note: Full-duplex software UART for LPC111x and LPC13xx (v.1.0)
- Leaflet: Low-power Cortex-M3 based microcontrollers simplify USB designs; NXP 72 MHz, 32-bit Cortex-M3™ microcontrollers LPC1300 (v.1.1)
- Application note: DSP library for LPC1700 and LPC1300 (v.3.0)
- Application note: USB In-System Programming with the LPC1300 (v.1.0)
- Report: Driving the LPC1300 with Murata resonators (v.1.0)
- Other type: LPC11xx/LPC13xx DALI release 1.0 (v.1.0)
- Software: AN11241: AES encryption and decryption software on LPC microcontrollers (v.1.0)
- Leaflet: Low-cost development platform for 32-bit LPC microcontroller family; NXP LPCXpresso (v.1.0)
- Application note: USB mass storage class with the LPC1300 on-chip driver (v.1.0)
- Software: AN10900 - FM+ I2C on LPC1300 (v.2.0)
- Application note: USB HID with the LPC1300 on-chip driver (v.1.0)
- Application note: UUencoding for UART ISP (v.1.0)
- Technical note: LPC134x sector lock mechanism for write/erase protection (v.1.0)
- Application note: USB composite device on the LPC134x (v.1.0)
- Technical note: LPC1343 (Cortex-M3) vs. LPC11U1x (Cortex-M0) (v.1.1)
- User manual: LPC1311/13/42/43 User manual (v.5.0)
- Application note: AN10905 - LPC1300 USB memrom (v.1.0)
- Application note: AN10918 - IEC60335 Class B library (with software) (v.1.0)
- Application note: AN11018 - USB composite device on the LPC134x (with software).zip (v.2.0)
- Application note: DSP library for LPC1700 and LPC1300 (v.3.0)
- Leaflet: NXP 70-MHz, 32-bit Cortex-M0™ microcontrollers LPC1300 (Chinese version) (v.1.0)
- Application note: Using M3 DSP library filter functions (v.1.0)
- Application note: AN11031 - PCB layout and ADC circuit recommendations for LPC1100 and LPC1300 (with software) (v.1.0)
- Application note: Decoding DTMF tones using M3 DSP library FFT function (v.1.0)
- Application note: AN10955 - Full-duplex software UART for LPC111x and LPC13xx (v.1.0)
- Application note: Using Code Read Protection in LPC1100 and LPC1300 (v.1.0)
- Application note: AN10986 - USB In-system programming with the LPC1300 (v.1.0)
- PCN: Customer Information Notification
