ITT Cannon, LLC
KPT01E22-55S的详细信息
| Datasheets： | |
|---|---|
| KPT01E22-55S Drawing： | |
| Mil-DTL 26482 (KPSE,KPT,MS)： | |
| KPT / KPSE / KPTC Catalog： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Circular Connectors |
| Series： | MIL-DTL-26482 Series I, KPT |
| Packaging ： | Bulk |
| Connector Type： | Receptacle, Female Sockets |
| Number of Positions： | 55 |
| Shell Size - Insert： | 22-55 |
| Shell Size, MIL： | - |
| Mounting Type： | Free Hanging (In-Line) |
| Termination： | Solder Cup |
| Fastening Type： | Bayonet Lock |
| Orientation： | N (Normal) |
| Ingress Protection： | Environment Resistant |
| Shell Material, Finish： | Aluminum Alloy, Olive Drab Cadmium Plated |
| Contact Finish： | Gold |
| Features： | - |
| Contact Finish Thickness： | 50µin (1.27µm) |
| Current Rating： | 7.5A |
| Voltage - Rated： | 600VAC, 850VDC |
| Operating Temperature： | -55°C ~ 125°C |
| Mating Products： | IKPSE08F22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE08E22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPT08F22-55P-ND - CONN PLUG 55POS INLINE W/PIN R/AIKPT08E22-55P-ND - CONN PLUG 55POS INLINE W/PIN R/AIKPSE08F22-55PF0-ND - CONN HSG R/A INLINE PLUG 55POSIKPSE08E22-55PF0-ND - CONN HSG R/A INLINE PLUG 55POSIKPSE06J22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE08P22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPT06J22-55P-ND - CONN PLUG 55POS INLINE W/PINIKPT08P22-55P-ND - CONN PLUG 55POS W/PIN INLINE R/AIKPSE06P22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE6F22-55PDX-ND - CONN PLUG 55POS W/PINIKPSE06F22-55PDX-ND - CONN PLUG 55POS W/PIN INLINEIKPSE06F22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPT06P22-55P-ND - CONN PLUG 55POS W/PIN INLINEIKPSE6E22-55PDN-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE06E22-55PDX-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE6E22-55PDX-ND - CONN PLUG 55POS CBL MNT W/PINSIKPSE06E22-55P-ND - CONN PLUG 55POS CBL MNT W/PINSIKPT06F22-55P-ND - CONN PLUG 55POS INLINE W/PINIKPT6E22-55PDN-ND - CONN PLUG 55POS W/PIN INLINEIKPT06E22-55P-ND - CONN PLUG 55POS W/PIN INLINEIKPSE06F22-55PF0-ND - CONN HSG INLINE MNT PLUG 55POS |
| Other Names： | IKPT01E22-55S |
