型号:

IRGI4061DPBF

厂商: International Rectifier International Rectifier
标准:
分类: 半导体IGBT - 单路
描述: igbt 600v 20a 43w to220fp
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

IRGI4061DPBF的详细信息

Datasheets:
IRGI4061DPBF:
Product Photos:
TO-220FP PKG:
Standard Package : 50
Category: Discrete Semiconductor Products
Family: IGBTs - Single
Series: -
Packaging : Tube
IGBT Type: Trench
Voltage - Collector Emitter Breakdown (Max): 600V
Current - Collector (Ic) (Max): 20A
Current - Collector Pulsed (Icm): 40A
Vce(on) (Max) @ Vge, Ic: 1.59V @ 15V, 11A
Power - Max: 43W
Switching Energy: 52µJ (on), 231µJ (off)
Input Type: Standard
Gate Charge: 35nC
Td (on/off) @ 25°C: 37ns/111ns
Test Condition: 400V, 11A, 22 Ohm, 15V
Reverse Recovery Time (trr): 60ns
Package / Case: TO-220-3
Mounting Type: Through Hole
Supplier Device Package: TO-220AB
