FGA180N33ATTU的详细信息
| Datasheets： | |
|---|---|
| FGA180N33AT： | |
| Product Photos： | |
| TO-3P-3,TO-247-3： | |
| PCN Design/Specification： | |
| Heat Sink Drawing Update 11/Feb/2014： | |
| PCN Packaging： | |
| Tape and Box/Reel Barcode Update 07/Aug/2014： | |
| Standard Package ： | 450 |
| Category： | Discrete Semiconductor Products |
| Family： | IGBTs - Single |
| Series： | - |
| Packaging ： | Tube |
| IGBT Type： | Trench |
| Voltage - Collector Emitter Breakdown (Max)： | 330V |
| Current - Collector (Ic) (Max)： | 180A |
| Current - Collector Pulsed (Icm)： | 450A |
| Vce(on) (Max) @ Vge, Ic： | 1.4V @ 15V, 40A |
| Power - Max： | 390W |
| Switching Energy： | - |
| Input Type： | Standard |
| Gate Charge： | 169nC |
| Td (on/off) @ 25°C： | - |
| Test Condition： | - |
| Reverse Recovery Time (trr)： | - |
| Package / Case： | TO-3P-3, SC-65-3 |
| Mounting Type： | Through Hole |
| Supplier Device Package： | TO-3PN |
