FBA08A12L1A的详细信息
| Datasheets： | |
|---|---|
| FBA08A： | |
| FB Series Part Number Guide： | |
| Fans & Blowers Catalog： | |
| Product Photos： | |
| FBA08A12L1A： | |
| Other Related Documents： | |
| Fan Agency Approvals： | |
| RoHS Information： | |
| FBA08A12L1A Material： | |
| Standard Package ： | 100 |
| Category： | Fans, Thermal Management |
| Family： | DC Fans |
| Series： | FBA |
| Voltage - Rated： | 12VDC |
| Size / Dimension： | Square - 80mm L x 80mm H x 25.5mm W |
| Air Flow： | 24.0 CFM (0.680m³/min) |
| Static Pressure： | 0.062 in H2O (15.4 Pa) |
| Bearing Type： | Hydro-wave (HWB) |
| Fan Type： | Tubeaxial |
| Features： | - |
| Noise： | 21 dB |
| Power (Watts)： | 0.82W |
| RPM： | 1900 RPM |
| Termination： | 2 Wire Leads |
| Ingress Protection： | - |
| Weight： | 0.22 lb (99.79g) |
| Operating Temperature： | 14 ~ 158°F (-10 ~ 70°C) |
| Current Rating： | 0.068A |
| Voltage Range： | 7 ~ 13.8VDC |
| Life Expectancy： | 50000 hrs @ 40°C |
| Material - Frame： | - |
| Material - Blade： | - |
| Associated Product： | FCC-000-ND - LEAD SET FOR FAN 3 CONDA1950TR-ND - CONN CONTACT 22-26AWG TIN CRIMPA1950CT-ND - CONN CONTACT 22-26AWG TIN CRIMPP11030-ND - LEAD SET FOR FAN 3CONDA1948-ND - CONN RECEPT 3POS 2MM CRIMP |
| Other Names： | FBA 08A12L1AFBA-08A12L1AP9736 |
