ED125/2DS的详细信息
| Datasheets： | |
|---|---|
| ED125/XDS： | |
| Product Photos： | |
| ED125/2DS： | |
| Other Related Documents： | |
| ED Part Number Breakdown： | |
| Standard Package ： | 50 |
| Category： | Connectors, Interconnects |
| Family： | Terminal Blocks - Wire to Board |
| Series： | ED125/DS |
| Packaging ： | Bulk |
| Number of Levels： | 1 |
| Positions Per Level： | 2 |
| Pitch： | 0.200" (5.08mm) |
| Mating Orientation： | Vertical with Board |
| Current： | 15A |
| Voltage： | 300V |
| Wire Gauge： | 14-22 AWG |
| Mounting Type： | Through Hole |
| Wire Termination： | Screw - Leaf Spring, Wire Guard |
| Features： | Interlocking (Side) |
| Color： | Blue |
| Operating Temperature： | -30°C ~ 105°C |
| Housing Material： | Polyamide (PA), Nylon |
| Contact Material - Plating： | Brass |
| Clamp Material - Plating： | Steel, Stainless |
| Screw Material - Plating： | - |
| Torque - Screw： | 0.5 Nm (4.4 Lb-In) |
| Screw Thread： | M3 |
| Dynamic Catalog： | ED125/DS and EDZ500/DS Series |
| Other Names： | ED1252DSED1611 |
