DAMN-7H2S-N-A197的详细信息
| Datasheets： | |
|---|---|
| DAMN7H2SNA197： | |
| D Sub Catalog： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub Connectors |
| Series： | Combo D®, D*M |
| Packaging ： | Bulk |
| Connector Style： | D-Sub, Combo |
| Connector Type： | Receptacle, Female Sockets |
| Number of Positions： | 7 (5 + 2 Power) |
| Number of Rows： | 2 |
| Shell Size, Connector Layout： | 2 (DA, A) - 7W2 |
| Contact Type： | Signal and Power |
| Mounting Type： | Panel Mount |
| Through Hole： | |
| Flange Feature： | Mating Side |
| Female Screwlock (4-40)： | |
| Termination： | Solder |
| Features： | Board Lock, Shielded |
| Shell Material, Finish： | Steel, Tin-Lead Plated |
| Contact Finish： | Gold |
| Contact Finish Thickness： | Flash |
| Ingress Protection： | - |
| Operating Temperature： | -55°C ~ 125°C |
| Voltage Rating： | - |
| Current Rating： | 40A, 7.5A |
| Housing Material： | Polyester |
| Color： | Black |
| Other Names： | 053512-2351535122351DAMN7H2SNA197IDAMN7H2SNA197IDAMN7H2SNA197-ND |
