CTX33-1A-R的详细信息
| Datasheets： | |
|---|---|
| CTX Series ECONO-PAC, OCTA-PAC/PLUS： | |
| Product Photos： | |
| CTX33 Series： | |
| Catalog Drawings： | |
| Parallel Connection Pin Out： | |
| Series Connection Pin Out： | |
| Ratio Transformer Pin Out： | |
| CTX-[1,2,(1,2)P,(1,2)A] Series Footprint： | |
| CTX-(1,1P,1A) Series： | |
| PCN Assembly/Origin： | |
| Multiple Devices 31/Aug/2013： | |
| Coiltronics Magnetics Facility 31/Aug/2013： | |
| Standard Package ： | 1,100 |
| Category： | Inductors, Coils, Chokes |
| Family： | Arrays, Signal Transformers |
| Series： | OCTA-PAC® PLUS |
| Packaging ： | Tape & Reel (TR) |
| Number of Coils： | 2 |
| Current： | 610mA |
| Inductance - Connected In Series： | 137.1µH |
| Inductance - Connected In Parallel： | 34.26µH |
| Tolerance： | ±25% |
| DC Resistance (DCR)： | 497.5 mOhm Max |
| Shielding： | Unshielded |
| Mounting Type： | Surface Mount |
| Package / Case： | Non Standard |
| Size / Dimension： | 0.450" L x 0.450" W (11.43mm x 11.43mm) |
| Height： | 0.165" (4.19mm) |
| Other Names： | CTX33-1ACTX33-1A-ND |
