Texas Instruments
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
COP8SCR9HVA8/63SN的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | No |
| Core： | COP8 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 10 MHz |
| Program Memory Size： | 32 kB |
| Data RAM Size： | 1 kB |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | PLCC-44 |
| Mounting Style： | SMD/SMT |
| Brand： | Texas Instruments |
| Interface Type： | SPI/USART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 37 |
| Number of Timers： | 3 |
| Program Memory Type： | Flash |
| Series： | COP8SCR9 |
| Factory Pack Quantity： | 25 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
COP8SCR9HVA8/63SN相关文档
- Function Diagram: fbd_snos537i
COP8SCR9HVA8/63SN应用笔记
- AN-453 COPS Based Automobile Instrument Cluster
- AN-662 COP800 Based Automated Security/Monitoring System
- AN-596 COP800 Mathpak
- AN-734 MF2 Compatible Keyboard with COP8 Microcontrollers
- Replcing Dedictd Protocl Contrl w/Code Eff & Config Microc-Low Spd CAN Ntwk Apps
- AN-579 MICROWIRE/PLUS Serial Interface
- AN-823 Time Keeping Using a COP800 Microcontroller
- AN-663 Sound Effects for the COP800 Family
- AN-739 RS-232C Interface with COP800
- AN-761 Electronic Fuzing
- AN-824 Eight Channel Eight Bit PWM Controller
- AN-952 Low Cost A/D Conversion Using COP800
- AN-587 C in Embedded Systems and the Microcontroller World
- AN-329 Implementing an 8-Bit Buffer in COPS
- AN-714 Using COP800 Devices to Control DC Stepper Motors
- AN-413 Disk Interface Design Guide and Users Manual
