型号:

C3960BA

厂商: Arcolectric
标准:
分类: 机电产品拨动开关
描述: switch toggle dpdt 16a 125v
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

C3960BA的详细信息

Datasheets:
3900 Series:
Switches, Fuseholders Spec:
Product Photos:
C3972BA:
Product Training Modules:
Switches:
RoHS Information:
RoHS Declaration:
Standard Package : 100
Category: Switches
Family: Toggle Switches
Series: 3900
Packaging : Bulk
Circuit: DPDT
Switch Function: On-On
Current Rating: 16A (AC), 14A (DC)
Voltage Rating - AC: 125V
Voltage Rating - DC: 36V
Actuator Type: Standard Round
Actuator Length: 17.50mm
Illumination: Non-Illuminated
Illumination Type, Color: -
Illumination Voltage (Nominal): -
Mounting Type: Panel Mount
Panel Cutout Dimensions: Circular - 12.70mm Dia
Termination Style: Quick Connect - 0.250" (6.3mm)
Bushing Thread: 15/32-32
Ingress Protection: -
Features: -
Actuator Material: -
Electrical Life: -
Operating Temperature: -
Dynamic Catalog: 3900 Series
Associated Product: 1091-1096-ND - BOOT FULL TOGGLE W/METAL NUT
Other Names: 1091-1030
