C146 10F048 807 1的详细信息
| Datasheets： | |
|---|---|
| Heavy-Mate Connector Catalog： | |
| Standard Package ： | 5 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | heavy|mate®, C146 E |
| Packaging ： | Bulk |
| Connector Type： | Base - Box Mount |
| Style： | Side Entry |
| Size： | E48 |
| Lock Location： | Side Clip on Base Bottom |
| Thread Size： | PG36 |
| Size / Dimension： | 5.197" L x 4.724" W x 3.976" H (132.00mm x 120.00mm x 101.00mm) |
| Housing Color： | - |
| Features： | Cover |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum Alloy, Die Cast |
| Housing Finish： | - |
| Operating Temperature： | -40°C ~ 100°C |
| For Use With： | C146 10B024 104 1-ND - INSERT FEMALE 24POS+1GND SCREWC146 10B024 102 1-ND - INSERT FEMALE 24POS+1GND SCREWC146 10B024 004 1-ND - INSERT FEMALE 24POS+1GND SCREWC146 10B024 002 1-ND - INSERT FEMALE 24POS+1GND SCREWC146 10A024 104 1-ND - INSERT MALE 24POS+1GND SCREWC146 10A024 102 1-ND - INSERT MALE 24POS+1GND SCREWC146 10A024 004 1-ND - INSERT MALE 24POS+1GND SCREWC146 10A024 002 1-ND - INSERT MALE 24POS+1GND SCREW |
| Other Names： | C14610F0488071 |
