BGU7003,132的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | RF Amplifier |
| RoHS： | Yes |
| Type： | Low Noise Amplifier |
| Operating Frequency： | 40 MHz to 6 GHz |
| Power Gain Typ： | 18.3 dB |
| Noise Figure： | 0.8 dB |
| P1dB： | - 20.1 dBm |
| Output Intercept Point： | 18.1 dBm |
| Operating Supply Voltage： | 2.5 V |
| Supply Current： | 5 mA |
| Test Frequency： | 1.575 GHz |
| Maximum Operating Temperature： | + 150 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | XSON-6 |
| Packaging： | Reel |
| Brand： | NXP Semiconductors |
| Maximum Power Dissipation： | 70 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Channels： | 1 Channel |
| Factory Pack Quantity： | 5000 |
BGU7003,132相关文档
- Other type: GPS, LNA, Sensitivity, Jamming, Cohabitation, TTFF; Global Position System Low Noise Amplifier (v.1.0)
- User manual: User Manual for the BGU7003 GPS LNA demo boards v2.0 (v.1.0)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_2V4_55mA_D SPICE model (v.1.3)
- User manual: User manual for the BGU7003 868MHz LNA evaluation board (v.1.0)
- Application note: BGU7003 1900MHz to 2100MHz LNA Application (v.1.0)
- Other type: Tablet and Smartphone Applications Reference Document (v.1.0)
- Application note: BGU7003 LNA application for GPS L2 band (v.1.0)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_53V9_09mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_88V6_82mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_53V4_55mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_53V6_82mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_2V9_09mA_D SPICE model (v.1.3)
- Other type: BGU7003_S_NF_Parameters (v.1.0)
- User manual: User manual for the BGU7003 100MHz LNA evaluation board (v.1.1)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_2V2_73mA_D SPICE model (v.1.3)
- S-parameter: S-parameter BGU7003 (v.1.0)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_1_8V2_73mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_off_state_D SPICE model (v.1.3)
- User manual: User manual for the BGU7003 2.4GHz LNA evaluation board (v.1.1)
- Leaflet: NXP SiGe:C GPS LNAs (v.1.0)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_53V13_6mA_D SPICE model (v.1.3)
- Application note: CMMB LNA with BGU7003, 400 MHz to 800 MHz (v.1.0)
- Line card: Application guide: Flat-panel TV sets (v.2.1)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_88V13_6mA_D SPICE model (v.1.3)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_2V6_82mA_D SPICE model (v.1.3)
- Application note: BGU7003 400MHz and 900 MHz applicaiton (v.1.1)
- SPICE model: PProgTestNoiseATS_dataTestdata_NetBGU7002_BGU7003_RN20082092BGU7003_B1_high_freq_bias_loop_2_88V9_09mA_D SPICE model (v.1.3)
