AT89C51ED2-RDTUM的详细信息
Manufacturer: | Atmel |
---|---|
Product Category: | 8-bit Microcontrollers - MCU |
RoHS: | Yes |
Brand: | Atmel |
Core: | 8051 |
Data Bus Width: | 8 bit |
Maximum Clock Frequency: | 60 MHz |
Program Memory Size: | 64 kB |
Data RAM Size: | 2 kB |
On-Chip ADC: | No |
Operating Supply Voltage: | 2.7 V to 5.5 V |
Maximum Operating Temperature: | + 85 C |
Package / Case: | VQFP-64 |
Mounting Style: | SMD/SMT |
Interface Type: | SPI, UART |
Minimum Operating Temperature: | - 40 C |
Number of Programmable I/Os: | 50 |
Number of Timers: | 3 |
Processor Series: | AT89x |
Program Memory Type: | Flash |
Series: | 89C |
Factory Pack Quantity: | 800 |
Supply Voltage - Max: | 5.5 V |
Supply Voltage - Min: | 2.7 V |
