ADS7961SDBTG4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 16 Channel |
| Brand： | Texas Instruments |
| Architecture： | SAR |
| Conversion Rate： | 1 MS/s |
| Resolution： | 8 bit |
| Input Type： | Single-Ended |
| Interface Type： | Serial, SPI |
| Operating Supply Voltage： | 2.7 V to 5.25 V |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-38 |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 1 |
| Packaging： | Tube |
| Series： | ADS7961 |
| SNR： | 49 dB |
| Factory Pack Quantity： | 50 |
| Voltage Reference： | External |
| Unit Weight： | 124 mg |
ADS7961SDBTG4相关文档
- Evaluation Kits: ADS7961 Performance Demonstration Kit (PDK)
- Evaluation Kits: ADCPro(TM) Analog-to-Digital Converter Evaluation Software
- Function Diagram: fbd_slas605a
ADS7961SDBTG4应用笔记
- What Designers Should Know About Data Converter Drift
- Interleaving Analog-to-Digital Converters
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- Principles of Data Acquisition and Conversion
- Determining Minimum Acquisition Times for SAR ADCs, part 1 (Rev. A)
- Determining Minimum Acquisition Times for SAR ADCs, part 2
