| Datasheets： |
|
| 640929： |
|
| Product Photos： |
|
| 8-640929-1： |
|
| RoHS Information： |
|
| 8-640929-1 Statement of Compliance： |
|
| RoHS 2 Statement： |
|
| 3D Model： |
|
| 8-640929-1.pdf： |
|
| Standard Package ： |
1,000 |
| Category： |
Connectors, Interconnects |
| Family： |
Terminals - Quick Connects, Quick Disconnect Connectors |
| Series： |
Faston, PIDG, AMP |
| Packaging ： |
Bulk |
| Terminal Type： |
Standard |
| Gender： |
Female |
| Tab Width： |
0.110" (2.79mm) |
| Tab Thickness： |
0.020" (0.51mm) |
| Tab Length： |
0.250" (6.35mm) |
| Length - Overall： |
0.800" (20.32mm) |
| Termination： |
Crimp |
| Wire Gauge： |
14-16 AWG |
| Insulation： |
Non-Mating End Insulated |
| Mounting Type： |
Free Hanging (In-Line) |
| Features： |
- |
| Color： |
Blue |
| Contact Material： |
Brass |
| Contact Finish： |
Tin |
| Insulation Diameter： |
0.170" (4.32mm) |
| Associated Product： |
679305-1-ND - TOOL HEAD TETRA CRIMP ADPT ASSY59827-1-ND - TOOL TETRA-CRIMP DIE 16-14AWGA120078-ND - TOOL HAND CRIMP PIDG 14-16AWGA27982-ND - TOOL HAND CRIMP PIDG 14-16 AWGA27992-ND - TETRA-CRIMP HT ASSYA9811-ND - TOOL CRIMP INSUL TERM W/DIE SETA9991-ND - DIESET SPLICE TERMINALS |
